ZO 4x30i-RD MG5 | H&K MG5 Dedicated
[Code: 10238836]
4x30i targeting optics deliver excellent optical performance, particularly in adverse visibility conditions. The twilight performance is extraordinary for targeting optics: With an exit pupil of 7.5 mm, the 4x30i is particularly well-suited for the twilight and practically optimised for the human eye.
This benefit now carries over to the use of a night-vision attachment.
Optimised adjustment of the eye relief, pupil diameter and field of view with maximum edge definition make the 4x30i targeting optics a superior targeting instrument for intermediate ranges.
This benefit now carries over to the use of a night-vision attachment.
Optimised adjustment of the eye relief, pupil diameter and field of view with maximum edge definition make the 4x30i targeting optics a superior targeting instrument for intermediate ranges.
Features & Benefits
4x magnification with a very large field of view
Eye relief: 6.5 cm
Reticle illumination powered by
1 AA battery (1.2 – 3.5 V)
| Optical data | |
| Magnification |
4 x
|
| Lens diameter |
30 mm
|
| Exit pupil |
7. 5 mm
|
| Eye relief |
65 mm
|
| Field of view (at 1000 m) |
8° / 140 m
|
| Dioptre adjustment |
fixed (-0.5 dpt)
|
| Transmission |
> 80%
|
| Elevation/azimuth click stops |
0.2 mrad (2 cm / 100 m)
|
| Max. elevation adjustment range |
±100 cm / 100 m
|
| Max. azimuth adjustment range |
±100 cm / 100 m
|
| Reticle |
MG5
|
| Electrical data | |
| Power supply |
1.2 - 3.6 V
|
| Battery size |
1 x AA mignon
|
| Service life at 25°C |
> 1000 hl
|
| Brightness levels |
6 day levels / 3 night levels
|
| Ambient conditions | |
| Environmental test |
(MIL-STD 1913) MIL-STD-810G, DIN ISO 9022 (excerpt)
|
